High-resolution intraoral digital sensors for precise radiographic imaging. USB direct connection — no interface box required. TWAIN compatible with most imaging software.
Smaller active area designed for pediatric patients, posterior imaging in smaller mouths, and veterinary applications. Ideal when space is limited.
Standard adult-size sensor with larger active area for comprehensive anterior and posterior imaging. The most versatile option for general dental practice.
27+ lp/mm resolution with 18 µm pixel size — capturing fine anatomical detail for confident diagnosis.
| Specification | Size 1 | Size 2 |
|---|---|---|
| Active Area | 20 × 30 mm | 26 × 36 mm |
| Active Pixels | 1110 × 1666 | 1442 × 1998 |
| Pixel Size | 18 µm | |
| Resolution | 27+ lp/mm | |
| Thickness | 4.8 mm — one of the thinnest on the market | |
| Connection | USB 2.0 Direct (no interface box required) | |
| Cable Length | 2.7 m | |
| IP Rating | IP68 (dust & water resistant, submersible) | |
| File Format | DICOM | |
| Driver | TWAIN driver included — compatible with most imaging software | |
| Power | Computer-supplied via USB (no mains power) | |
| Design | Rounded corners, flat surface, silicone protective cover | |
| Warranty | 2 years | |
